云原生套件

1cd /Users/fewbox/.ssh
2ssh-keygen
3#/Users/fewbox/.ssh/id_ed25519: id_rsa
4cat /Users/fewbox/.ssh/id_rsa.pub
5#复制Public Key打开远程机器
6vi ~/.ssh/authorized_keys
7chmod 600 ~/.ssh/authorized_keys
8chomd 700 ~/.ssh
9#PubkeyAuthentication yes
10vi /etc/ssh/sshd_config
11systemctl restart sshd
12#ssh -v 192.168.1.111

1Host Master
2  HostName 192.168.1.111
3  User root
4  IdentityFile /Users/fewbox/.ssh/id_rsa

1cd /etc/sysconfig/network-scripts/
2vi ifcfg-enp0s3
3systemctl restart network

1systemctl stop firewalld
2systemctl disable firewalld
3sed -i  '/^SELINUX=/ c  SELINUX=disabled' /etc/selinux/config
4setenforce 0

1# TODO

1sed -i 's/.*swap.*/#&/' /etc/fstab
2free -m

1cat <<EOF | sudo tee /etc/sysctl.d/k8s.conf
2net.bridge.bridge-nf-call-ip6tables = 1
3net.bridge.bridge-nf-call-iptables = 1
4EOF
5sysctl --system

1yum install ipset ipvsadm
2cat <<EOF >  /etc/sysconfig/modules/ipvs.modules
3#!/bin/bash
4modprobe -- ip_vs
5modprobe -- ip_vs_rr
6modprobe -- ip_vs_wrr
7modprobe -- ip_vs_sh
8modprobe -- nf_conntrack
9EOF
10chmod +x /etc/sysconfig/modules/ipvs.modules
11/bin/bash /etc/sysconfig/modules/ipvs.modules
12lsmod | grep -e ip_vs -e nf_conntrack_ipv4

1# 配置软件源(E.G)
2vi /etc/yum.repos.d/kubernetes.repo
3# yum --showduplicates list kubelet
4# 清理
5yum remove kubelet
6yum remove kubeadm
7# 安装
8yum install kubeadm
9# 查看kubeadm版本
10kubeadm version
11# 查看kubelet版本
12kubelet --version
13# 查看Kubeadm安装镜像
14kubeadm config images list
15# 更新containerd配置
16containerd config default > /etc/containerd/config.toml
17vi /etc/containerd/config.toml
18# !!! registry.k8s.io/pause:3.6 改为 registry.aliyuncs.com/google_containers/pause:3.9 并且增加如下设置，类似daemon.json （E.G）#
19# 更换image
20sandbox_image = "registry.aliyuncs.com/google_containers/pause:3.9"
21# 支持http
22[plugins."io.containerd.grpc.v1.cri".registry.mirrors."registry.fewbox.lan:5000"]
23endpoint = ["http://registry.fewbox.lan:5000"]
24# 更新Containerd的Endpoint配置
25cat > /etc/crictl.yaml <<EOF
26runtime-endpoint: unix:///var/run/containerd/containerd.sock
27image-endpoint: unix:///var/run/containerd/containerd.sock
28timeout: 0
29debug: false
30pull-image-on-create: false
31EOF
32# 重启Containerd
33systemctl daemon-reload && systemctl enable containerd && systemctl restart containerd
34# 查看containerd镜像 ！！！！！
35crictl images

1[kubernetes]
2name=Kubernetes
3baseurl=https://mirrors.aliyun.com/kubernetes/yum/repos/kubernetes-el7-x86_64
4enabled=1
5gpgcheck=0

1# 初始化集群
2kubeadm init --kubernetes-version=1.28.2 \
3--apiserver-advertise-address=192.168.1.13 \
4--image-repository registry.aliyuncs.com/google_containers \
5--service-cidr=10.96.0.0/12 \
6--pod-network-cidr=10.244.0.0/16 \
7#--ignore-preflight-errors=Swap \
8#--cri-socket=unix:///var/run/cri-dockerd.sock
9# 优化操作方式
10yum -y install bash-completion
11bash /usr/share/bash-completion/bash_completion
12bash
13. start.sh
14# 配置CoreDNS网络
15wget https://raw.githubusercontent.com/flannel-io/flannel/master/Documentation/kube-flannel.yml
16vi kube-flannel.yml # ☢️❗️❗️❗️☢️Change 10.244.0.0/16
17kubectl apply -f kube-flannel.yml
18# 检查证书过期时间
19kubeadm certs check-expiration
20# kubeadm certs renew all
21# 安装Metrics
22wget https://github.com/kubernetes-sigs/metrics-server/releases/latest/download/components.yaml
23docker pull registry.cn-hangzhou.aliyuncs.com/google_containers/metrics-server:v0.6.4
24vi components.yaml # (E.G)
25k apply -f components.yaml
26# 显示Join集群命令
27# kubeadm reset 选做
28kubeadm token create --print-join-command

1# 加入集群
2kubeadm join 192.168.1.111:6443 --token fpzqbu.2gtsrknkcbb9izn3 --discovery-token-ca-cert-hash sha256:b1c7928254d7c838d0d633ff5d9f248331571be4780be0ff40e7035df3bb7bf4

1# 下载
2curl -L https://istio.io/downloadIstio | sh - # 或者访问https://istio.io/downloadIstio，执行得到的shell脚本，或者访问https://github.com/istio/istio/releases进行下载
3# 设置环境变量
4cd istio-1.19.3
5export PATH=$PWD/bin:$PATH
6# 列出配置模板
7istioctl profile list
8istioctl install # default
9# 设置istio（可选）
10# k label namespace default istio-injection=enabled

1. ./fewbox-installl.sh # 注册用户
2kcd fewbox-system
3k get ns fewbox-system
4k get sa fewbox
5k get clusterrolebinding fewbox # cluster-admin - fewbox/fewbox-admin
6k get cm packingtable
7k get deploy packingtable
8k get crd kits.fewbox.com

1k apply -f ./component/infrastructure/boot.yaml
2k get sa nfs-client-provisioner
3k get clusterrole nfs-client-provisioner-runner
4k get clusterrolebinding run-nfs-client-provisioner
5k get deploy nfs-client-provisioner
6k get sc managed-nfs-storage

1k apply -f ./component/middleware/boot.yaml
2k get pvc datadir-fewbox-mysql-0
3k get pvc fewbox-redis
4k get pvc persistence-fewbox-rabbitmq-server-0
5k get pv # From PVC
6#k get cm npmregistry
7k get cm fewbox-rabbitmq-plugins-conf  #??
8k get cm fewbox-rabbitmq-server-conf
9k get deploy fewbox-redis
10k get svc fewbox-mysql-instances
11k get svc fewbox-rabbitmq
12k get svc fewbox-rabbitmq-nodes
13k get svc fewbox-redis
14k get crd rabbitmqclusters.rabbitmq.com
15k get clusterrole rabbitmq-cluster-operator-role
16k get sa fewbox-mysql-sidecar-sa
17k get sa fewbox-rabbitmq-server
18k get rolebinding fewbox-mysql-sidecar-rb
19k get rolebinding fewbox-rabbitmq-server
20k get rmq fewbox-rabbitmq
21#Username
22k get secret fewbox-rabbitmq-default-user -o jsonpath="{.data.username}" | base64 --decode
23k get secret fewbox-rabbitmq-default-user -o jsonpath="{.data.password}" | base64 --decode
24#RabbitMQ
25k exec -it fewbox-rabbitmq-server-0 bash
26k port-forward service/fewbox-rabbitmq amqp --address 0.0.0.0
27k port-forward service/fewbox-rabbitmq management --address 0.0.0.0
28#rabbitmq-plugins enable rabbitmq_management
29#MySQL
30k exec -it fewbox-mysql-0 bash
31# SQL >
32# mysqlsh fewbox@localhost --sql
33# set global read_only=0;
34k port-forward service/fewbox-mysql-instances mysql --address 0.0.0.0
35#MongoDB

1export KUBECONFIG=/etc/kubernetes/admin.conf
2alias k=kubectl  #~/.bashrc
3source <(kubectl completion bash)
4source <(kubectl completion bash | sed s/kubectl/k/g)
5alias kcd='kubectl config set-context $(kubectl config current-context) --namespace'
6# export CALICO_DATASTORE_TYPE=kubernetes
7# export CALICO_KUBECONFIG=/etc/kubernetes/admin.conf
8# export PATH=$PATH:/root/istio-1.6.2/bin/

1image: registry.aliyuncs.com/google_containers/metrics-server:v0.6.4
2args:- --cert-dir=/tmp
3- --secure-port=4443
4- --kubelet-preferred-address-types=InternalIP,ExternalIP,Hostname
5- --kubelet-use-node-status-port
6- --kubelet-insecure-tls # Add this line (New Version)

1# 资源不足查看
2kubectl describe node
3# 查看资源占比
4kubectl describe node |grep -E '((Name|Roles):\s{6,})|(\s+(memory|cpu)\s+[0-9]+\w{0,2}.+%\))

1# 下载镜像
2docker pull anoxis/registry-cli
3# 执行镜像命令
4#---列出所有image和tag---#
5docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000
6#---列出所有image，tag和layer---#
7docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000 --layers
8#---列出部分image或tag---#
9docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000 -i  fewbox/auth fewbox/empty
10docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000 -i  fewbox/auth fewbox/empty --layers
11#---仅保留最近10个版本---#
12docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000 --delete
13#---仅保留最近5个版本---#
14docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000 --delete --num 5
15#---通配符---#
16docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000 --delete --tags-like "snapshot-" "^stable-[0-9]{4}.*"
17docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000  -i fewbox/template-app --delete-all
18#---Dryrun---#
19docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000  -i fewbox/template-app --delete-all --dry-run
20#---删除特定时间image所有tag---#
21docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000  --dry-run --delete-by-hours 24 --keep-tags c59c02c25f023263fd4b5d43fc1ff653f08b3d4x --keep-tags-like latest
22docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000  docker run --rm anoxis/registry-cli -r http://192.168.1.38:5000  --delete --tags-like "snapshot-" "^stable-[0-9]{4}.*" --keep-tags "stable" "latest"
23#---删除特定image所有tag---#
24--dry-run --delete --keep-by-hours 72 --keep-tags-like latest
25#---!!!!!!!!!!!清理GC!!!!!!!!!!!---#
26# 删除Repository!!!
27
28docker ps
29docker exec {容器id} registry garbage-collect --delete-untagged /etc/docker/registry/config.yml
30docker stop {容器id}
31docker start {容器id}
